Select "Display" to display some or all the S parameter traces of the generated touch-
stone file that are applied for deembedding. A dialog then allows you to select the S
parameter traces to be imported to new memory traces:
6.13.5.5
<Deembedding Tool> Errors Dialog
If running the related deembedding tool causes errors, a dialog provides additional
information:
Figure 6-56: EZD error messages
Figure 6-57: Delta-L error messages
6.13.5.6 ISD Advanced Settings
For details see the ISD User Guide.
Offset Embed Softtool
