Concepts and Features
R&S
®
ZNB/ZNBT
234User Manual 1173.9163.02 ─ 55
5.7.18 RFFE GPIO Interface
Internal: Option R&S ZN-B15 (R&S ZNB only)
External: Option R&S ZN-Z15
The trend in mobile radio communication is towards higher scale of integration of exter-
nal components such as filters, switches, low noise and power amplifiers. The require-
ment for test and measurement equipment is to make it possible to control those com-
ponents directly from the instrument without the need of additional external tools, e.g. a
USB to RFFE adapter.
For these kinds of applications, Rohde & Schwarz has developed an RFFE-GPIO
extension board for the R&S ZNB/ZNBT. This board is equipped with a 25-pin female
connector interface providing 2 independent RF Front-End (RFFE) interfaces accord-
ing to the MIPI® Alliance "System Power Management Interface Specification" and 10
General Purpose Input/Output (GPIO) pins. RFFE command execution and GPIO volt-
age settings can be synchronized with the sweep (sweep sequencer functionality);
however, RFFE read is not supported in sweep sequencer mode.
Versions and variants
The following variants of the RFFE-GPIO extension board are available:
R&S ZN-B15 variant 02, order number 1323.9355.02
R&S ZN-B15 variant 03, order number 1323.9355.03, including current and voltage
measurements for all RFFE and GPIO pins
R&S ZN-Z15 variant 02, order number 1325.5905.02, the external version of
R&S ZN-B15 variant 02
R&S ZN-Z15 variant 03, order number 1325.5905.03, the external version of
R&S ZN-B15 variant 03
Information about the voltage and current levels is available in Chapter 11.3.5, "RFFE -
GPIO Interface ", on page 1439.
For the R&S ZNBT, only the external versions R&S ZN-Z15 can be used.
Currently, the external versions have to be connected via Direct Control, which in
turn requires Device Control option R&S ZNB/ZNBT-B12.
No matter if connected internally or externally, there is no need to perform any kind
of calibration or alignment of the extension board. The analyzer firmware automati-
cally detects and supports it. The controlled devices can be hot-plugged.
The analyzer firmware only supports a single RFFE GPIO interface board.
Mounting the internal unit (R&S ZNB only)
The internal version R&S ZN-B15 of the RFFE-GPIO extension board uses the same
slot as the Bias Tee option R&S ZNB-B1 (see Chapter 5.7.12, "Bias Tees (R&S ZNB
only)", on page 231). In case you have already installed the Bias Tee option, you have
to remove it first.
