Remote command:
CALCulate:MARKer:COUPled:TYPE
Reset Marker Coupling
Convenience function for disabling marker coupling and setting the Coupling Type to
"All" (default).
Remote command:
CALCulate:MARKer:COUPled[:STATe] OFF
CALCulate:MARKer:COUPled:TYPE ALL
6.8 Stimulus Softtool
On the "Stimulus" softtool, you can access to the stimulus parameters of the active
channel. If the active trace is represented in Time Domain, it also allows you to config-
ure the "observation interval".
Access: STIMULUS – [START] | [STOP] | [CENTER] | [SPAN] hardkey
●
While in Cartesian diagrams the x-axis represents the stimulus values, in polar and
Smith diagrams this direct relation is lost. In any case, a marker can be used to dis-
play the stimulus value of a given trace point.
For "Time Domain" traces, points in the "observation interval" are interpreted as
stimulus values.
●
All stimulus settings except the "Time Domain X-Axis" settings are channel set-
tings. "Time Domain X-Axis" applies to the active (time domain) trace only.
Background information
Refer to the following sections:
●
Chapter 5.1.3, "Traces, Channels and Diagrams", on page 80
●
Chapter 4.3.6.2, "Setting the Sweep Range", on page 66
●
Chapter 4.3.6.6, "Set by Marker", on page 68
6.8.1 Stimulus Tab
Defines the sweep range in the current channel, depending on the sweep type.
Related Settings
Refer to the following sections:
●
Chapter 5.1.4.3, "Stimulus and Sweep Types", on page 87
●
Chapter 6.10.2, "Sweep Type Tab", on page 394
Stimulus Softtool
