R&S ZNB - 6.14.4.3 Page Setup Tab; 6.14.5 Trace Data Tab; 6.14.6 More Tab

GUI Reference
R&S
®
ZNB/ZNBT
627User Manual 1173.9163.02 ─ 55
Printers can be installed using the Windows
®
"Devices and Printers" functionality; see
also Chapter 4.1.9.4, "Connecting a Printer", on page 25.
Print Options
Selects the color scheme to be used for printing.
Remote command:
HCOPy:PAGE:COLor
6.14.4.3 Page Setup Tab
The "Page Setup" settings are visualized in the preview page in the lower part of the
dialog.
Tip: The printer settings are not affected by a preset of the R&S ZNB/ZNBT. Use the
"Remote" tab in the System Config Dialog to restore default settings.
6.14.5 Trace Data Tab
See Chapter 6.5.11, "Trace Data Tab", on page 333.
6.14.6 More Tab
The "More" buttons load simulation data or close the VNA application.
File Softtool
