GUI Reference
R&S
®
ZNB/ZNBT
413User Manual 1173.9163.02 ─ 55
Sweep Active Channel
Apply the sweep control settings to the active channel only. The number of sweeps in a
"Single" sweep sequence is equal to the number of "Sweeps" in the active channel.
The table lists all channels in the active recall set and allows you to define individual
numbers of sweeps for all channels. When a new channel is selected, the analyzer
uses its specific number of sweeps.
Remote command:
INITiate<Ch>[:IMMediate]:SCOPe SINGle
[SENSe<Ch>:]SWEep:COUNt
6.11 Cal Softtool
The "Cal" softtool provides all functions related to system error calibration, scalar
power calibration, and "SMARTerCal".
Access: CHANNEL – [CAL]
6.11.1 Start Cal Tab
The "Start Cal" tab provides access to all functions for automatic or manual calibration.
Calibration of the R&S ZNB/ZNBT is a fully guided process.
Background information
Refer to the following sections:
●
Chapter 5.5, "Calibration", on page 147
●
Chapter 5.5.5, "Automatic Calibration", on page 166
●
Chapter 5.5.6, "Scalar Power Calibration", on page 173
●
Chapter 5.5.7, "SMARTerCal", on page 179
●
Chapter 5.1.5, "Data Flow", on page 89
It is possible to set up, perform and activate multiple system error corrections or
SMARTerCals in a single calibration procedure. However, this Multiple Cal in Calibra-
tion Wizard feature is disabled by default and has to be activated in the "Calibration"
tab of the "System Config" dialog.
Cal Softtool
