Instrument Messages...
Opens the System Configuration dialog with the Messages Tab selected. From there
you can configure the display of instrument messages as information popups, in partic-
ular the display of remote control command errors.
6.17.4 External Devices Tab
Allows you to set up and configure external power meters, generators and calibration
units and to enable error logging for the current session.
Background information
Refer to the following sections:
●
Chapter 5.7.25, "External Power Meters", on page 241
●
Chapter 5.7.26, "External Generators", on page 243
●
Chapter 5.5.5, "Automatic Calibration", on page 166
6.17.4.1 Controls on the External Devices Tab
The buttons in the "External Devices" panel open the following dialogs:
●
"Power Meters...", see Chapter 6.17.4.2, "External Power Meters Dialog",
on page 719
●
"Power Meter Config...", see Chapter 6.17.4.3, "External Power Meter Config Dia-
log", on page 722
This button is active only if at least one external power meter is online (physically
connected, switched on, ready to be used).
●
"Generators...", see Chapter 6.17.4.4, "External Generators Dialog", on page 723
Switch matrices can be configured on the "External Ports" tab, see Chapter 6.17.5.3,
"External Matrices Dialog", on page 729 and Chapter 6.17.5.5, "Switch Matrix RF
Connections Dialog", on page 734.
