GUI Reference
R&S
®
ZNB/ZNBT
362User Manual 1173.9163.02 ─ 55
Remote command:
CALCulate<Chn>:MARKer<Mk>:REFerence[:STATe]
CALCulate<Chn>:MARKer<Mk>:REFerence:Y
Add Marker
Adds a new marker to the active trace. Uses the next "free" marker number
Coupled Markers
Activates or deactivates Marker Coupling. The label indicates the selected Coupling
Type:
"Coupling Type" Label
"All" "Coupled Markers"
"Channel" "Coupled Markers in <name of active channel>"
"Diagram" "Coupled Markers in <name of active diagram>"
Coupling also works if Tracking is enabled for Marker <m> in one trace. The Marker
<m> of the other traces then follow the movements of the tracked marker. The same
holds true for the reference marker.
Remote command:
CALCulate:MARKer:COUPled[:STATe]
6.7.2 Marker Props Tab
Modifies the properties of a marker created previously (see Chapter 6.7.1, "Markers
Tab", on page 359). The functions (except "Export Markers...") are unavailable if the
active trace contains no markers.
Marker Softtool
