Command Reference
R&S
®
ZNB/ZNBT
882User Manual 1173.9163.02 ─ 55
Parameters:
<Mode> CONTinuous | DISCrete
CONTinuous - marker can be positioned on any point of the
trace, and its response values are obtained by interpolation.
DISCrete - marker can be set to discrete sweep points only.
*RST: CONT
Example: Suppose that the active recall set contains an active trace no. 1.
CALC:MARK:MODE DISC; :CALC:MARK2:MODE CONT
Create marker 1 in discrete mode and marker 2 in continuous
mode.
CALC:MARK ON; MARK2 ON
Display the two markers. Due to the different modes the horizon-
tal positions can be different.
Manual operation: See "Discrete" on page 363
CALCulate<Chn>:MARKer<Mk>:NAME <MarkerName>
Defines a name for marker no. <Mk>. The marker doesn't have to be created before
(CALCulate<Chn>:MARKer<Mk>[:STATe] ON), the name can be assigned in
advance.
Suffix:
<Chn>
.
Channel number used to identify the active trace
<Mk> Marker number.
Parameters:
<MarkerName> Marker name (string parameter)
*RST: 'M1' for marker no. 1 etc.
Example: Suppose that the active recall set contains an active trace no. 1.
CALC:MARK:NAME '&$% 1'; :CALC:MARK ON
Create marker 1 named "&$% 1" and display the marker .
CALC:MARK:REF ON
CALC:MARK:REF:NAME 'Reference'
Display the reference marker and rename it "Reference".
Manual operation: See "Marker Name" on page 363
CALCulate<Chn>:MARKer<Mk>:REFerence[:STATe] <Boolean>
Creates the reference marker and assigns it to trace no. <Chn>.
Suffix:
<Chn>
.
Channel number used to identify the active trace
<Mk> This numeric suffix is ignored and may be set to any value.
Parameters:
<Boolean> ON | OFF - creates or removes the marker.
*RST: OFF
SCPI Command Reference
