Example: Suppose that the active recall set contains an active trace no. 1.
CALC:MARK:REF ON; :CALC:MARK ON
Create the reference marker and marker 1 and assign them to
trace no. 1. The default position of both markers is the center of
the sweep range.
Manual operation: See "On" on page 360
CALCulate<Chn>:MARKer<Mk>:REFerence:FORMat <OutFormat>
Sets/queries the output format for the (complex) value of the reference marker.
Suffix:
<Chn>
.
Channel number used to identify the active trace
<Mk> This numeric suffix is ignored and may be set to any value.
Parameters:
<OutFormat> MLINear | MLOGarithmic | PHASe | POLar | GDELay | REAL |
IMAGinary | SWR | LINPhase | LOGPhase | IMPedance |
ADMittance | DEFault | COMPlex | MDB | MLPHase |
MDPHase | MIMPedance | PIMPedance | PADMittance |
MADMittance | MPIMpedance | MPADmittance | INDX
DEFault means the reference marker is formatted according
the related trace's default marker format (see
CALCulate<Chn>:MARKer:DEFault:FORMat).
For the other marker formats, see CALCulate<Chn>:MARKer:
DEFault:FORMat and the description in "Marker Format"
on page 96.
*RST:
DEFault
Manual operation: See "Marker Format" on page 363
CALCulate<Chn>:MARKer<Mk>:REFerence:MODE <Mode>
Sets the reference marker to continuous or discrete mode. The marker doesn't have to
be created before (CALCulate<Chn>:MARKer<Mk>[:STATe] ON), the mode can be
assigned in advance.
Suffix:
<Chn>
.
Channel number used to identify the active trace
<Mk> This numeric suffix is ignored and may be set to any value.
Parameters:
<Mode> CONTinuous | DISCrete
CONTinuous - marker can be positioned on any point of the
trace, and its response values are obtained by interpolation.
DISCrete - marker can be set to discrete sweep points only.
*RST: CONT
