GUI Reference
R&S
®
ZNB/ZNBT
633User Manual 1173.9163.02 ─ 55
Once you have selected a measurement, you can finish the wizard and proceed to the
Fixture Compensation Dialog using the "Finish with Fixture Compensation" button.
6.15.2.3 TDR Stimulus Settings Dialog
This dialog allows you to configure the frequency sweep whose results are then used
for the time domain transformation and subsequent TDR simulation.
Access: SYSTEM – [APPLIC] > "TDR" > "TDR Setup" > "Stimulus..."
After the settings are made, the resulting sweep parameters are shown in the lower
part of the dialog, as can be seen in the screenshot below.
Opening the dialog automatically activates the Automatic Harmonic Grid function.
Applic Softtool
