R&S ZNB - 6.13.5.3 Measure DUT + Test Fixture

GUI Reference
R&S
®
ZNB/ZNBT
593User Manual 1173.9163.02 ─ 55
Remote command:
CALCulate:FMODel:ISD<Ph_pt>:COUPon:MEASure
CALCulate:FMODel:ISD<Ph_pt>:COUPon:MEASure:OPEN
CALCulate:FMODel:ISD<Ph_pt>:COUPon:MEASure:SHORt
CALCulate:FMODel:SFD<Ph_pt>:COUPon:MEASure
CALCulate:FMODel:EZD<Ph_pt>:COUPon:MEASure on page 845
Load File / 1x Open Preset / 1x Short Preset
Allows you to load the coupon properties from a Touchstone file (*.s*p”).
Remote command:
CALCulate:FMODel:ISD<Ph_pt>:COUPon:MEASure:FILename
CALCulate:FMODel:ISD<Ph_pt>:COUPon:MEASure:OPEN:FILename
CALCulate:FMODel:ISD<Ph_pt>:COUPon:MEASure:SHORt:FILename
CALCulate:FMODel:SFD<Ph_pt>:COUPon:MEASure:FILename
CALCulate:FMODel:EZD<Ph_pt>:COUPon:MEASure:FILename
Active
Before starting to measure the test coupon, use these checkboxes to indicate the
physical ports to which it is connected.
Table 6-5: Allowed numbers of active ports
"Sym 2x Thru" 1x Open, 1x Short other
Single Ended 2 1 or 2 1
Balanced 2 or 4 2 or 4 2
Remote command:
CALCulate:FMODel:ISD<Ph_pt>:COUPon[:STATe]
CALCulate:FMODel:SFD<Ph_pt>:COUPon[:STATe]
CALCulate:FMODel:EZD<Ph_pt>:COUPon[:STATe]
6.13.5.3 Measure DUT + Test Fixture
The "Measure DUT + Test Fixture" section allows you to measure the whole structure,
i.e. the DUT with the test fixture.
This section is not available for EZD.
Offset Embed Softtool
