CALCulate:FMODel:ISD<Ph_pt>:COUPon:MEASure:SHORt:FILename <String>
For a fixture modeling with the ISD tool and coupon type OPSHort1x (see
CALCulate:FMODel:ISD<Ph_pt>:COUPon:TYPE), this command loads the proper-
ties of the Short coupon from a Touchstone file.
Suffix:
<Ph_pt>
.
This suffix is ignored.
Parameters:
<String> Path to the Touchstone file, either absolute or relative to the cur-
rent directory (see MMEMory:CDIRectory)
Manual operation: See "Load File / 1x Open Preset / 1x Short Preset " on page 593
CALCulate:FMODel:ISD<Ph_pt>:COUPon:TYPE <CouponType>
Sets/gets the coupon type to be measured for a fixture modeling with the ISD tool.
Suffix:
<Ph_pt>
.
This suffix is ignored.
Parameters:
<CouponType> SYMMetric2x | OPEN1x | SHORt1x | OPSHort1x
Example: See Chapter 9.2.8, "Fixture Modeling", on page 1415
Manual operation: See "Coupon Type" on page 592
CALCulate:FMODel:ISD<Ph_pt>:COUPon[:STATe] <Boolean>
For a fixture modeling with the ISD tool, this command allows to specify the ports to
which the test coupon is connected.
This has to be defined before measuring the test coupon (using CALCulate:FMODel:
ISD<Ph_pt>:COUPon:MEASure or CALCulate:FMODel:ISD<Ph_pt>:COUPon:
MEASure:OPEN and CALCulate:FMODel:ISD<Ph_pt>:COUPon:MEASure:SHORt
).
Suffix:
<Ph_pt>
.
Physical port number
Parameters:
<Boolean> 1 (ON, true) if the test coupon is connected to port <Ph_pt>, 0
(OFF, false) otherwise
Example: See Chapter 9.2.8, "Fixture Modeling", on page 1415
Manual operation: See "Active" on page 593
CALCulate:FMODel:ISD<Ph_pt>:DCEXtrapolat <Boolean>
Defines whether the de-/embedding file generated by the ISD tool contains (extrapola-
ted) DC data.
