1 3 2 4
Upper Tone
DUT
1 2
Lower Tone
LO
Intermodulation Measurement Results
The intermodulation measurement provides two different types of results:
●
In the swept measurement, the analyzer performs a frequency or power sweep of
the two-tone stimulus signal and displays the selected intermodulation quantities
as a function of the lower-tone frequency or power.
