GUI Reference
R&S
®
ZNB/ZNBT
690User Manual 1173.9163.02 ─ 55
The info table is a possible container for info fields and can be placed to the bottom, to
the left, or to the right of the screen. See also Chapter 6.7.8, "Info Field Tab",
on page 379.
Remote command:
No command; display configuration only.
Info Window
Shows/hides the Info Window
Remote command:
DISPlay:IWINdow[:STATe]
Font Size
Scales the fonts in the diagrams. The scaling affects the trace and channel lists, and
the info fields.
Remote command:
DISPlay:RFSize
6.16.3.2 Define User Color Scheme Dialog
The "Define User Color Scheme" dialog modifies the predefined color schemes,
changing the colors and styles of the individual display elements. User-defined color
schemes can be saved to a file for later re-use.
Access: SYSTEM – [DISPLAY] > "Config" > "Define User Color..."
Related settings
Refer to "Color Scheme" on page 688.
Display Softtool
