Suffix:
<Ch>
.
Channel number
<DCInp> Number of DC INPUT connector on the rear panel, 1 to 4
Parameters:
<Voltage> DC voltage range. The entered numeric value is rounded up to
±300 mV, ±3 V, ±20 V. Values above +20 V are rounded down.
Default unit: V
Example:
SENSe1:DC2:RANGe 1; :DC2:RANGE?
Select a DC measurement at DC INPUT2 with an expected DC
voltage range of ±1 V. The value is rounded up; the response is
3.
Manual operation: See "Ranges" on page 286
8.3.14.11 [SENSe:]FREQuency...
The [SENSe:]... commands set frequency-related parameters, especially the mea-
surement and display ranges for the different sweep types. The frequency ranges for
the different instrument models are listed below; for more details refer to the data
sheet.
Table 8-16: Frequency ranges of R&S
ZNB/ZNBT analyzers
Frequency settings Start, Stop Center Span
R&S ZNB4 9 kHz to 4.5 GHz >9 kHz to <4.5 GHz 1 Hz to 4.499991 GHz
R&S ZNB8 /
R&S ZNBT8
9 kHz to 8.5 GHz >9 kHz to <8.5 GHz 1 Hz to 8.499991 GHz
R&S ZNB20 /
R&S ZNBT20
100 kHz to 20 GHz >100 kHz to <20 GHz 1 Hz to 19.9999 GHz
R&S ZNBT26 100 kHz to 26.5 GHz >100 kHz to <26.5 GHz 1 Hz to 26.4999 GHz
R&S ZNB40 variant 72 10 MHz to 40 GHz >10 MHz to <40 GHz 1 Hz to 39.99 GHz
R&S ZNB40 variants 82,
83 and 84
R&S ZNBT40
100 kHz to 40 GHz >100 kHz to <40 GHz 1 Hz to 39.9999 GHz
Option R&S ZNB-B1, Bias Tees
If option R&S ZNB-B1 is installed on a R&S ZNB4 or R&S ZNB8, the frequency range
starts at 100 kHz.
Bias Tees are not available for the R&S ZNBT.
[SENSe<Ch>:]FREQuency[:CW]....................................................................................1189
[SENSe<Ch>:]FREQuency:FIXed.................................................................................. 1189
[SENSe<Ch>:]FREQuency:CENTer............................................................................... 1190
[SENSe<Ch>:]FREQuency:CONVersion.........................................................................1190
[SENSe<Ch>:]FREQuency:CONVersion:ARBitrary.......................................................... 1191
