ON (1)
Use the recommended trace configuration, i.e. display each of
the traces in a separate diagram.
OFF (0)
Display all traces in a single diagram.
Options: R&S ZNB/ZNBT-K231
Manual operation: See "Trace" on page 615
CALCulate:FMODel:EZD...
Commands for Eazy Deembedding (see Chapter 5.7.8, "Eazy De-embedding Based
on IEEE 370", on page 228).
CALCulate:FMODel:EZD<Ph_pt>:COUPon:MEASure
For a fixture modeling with the Easy De-embedding (EZD) tool, this command starts
the measurement of the symmetrical 2xThru coupon at the active ports (see
CALCulate:FMODel:EZD<Ph_pt>:COUPon[:STATe] on page 845).
Suffix:
<Ph_pt>
.
This suffix is ignored.
Usage: Event
Options: R&S ZNB/ZNBT-K210
Manual operation: See "Measure / Measure Open / Measure Short" on page 592
CALCulate:FMODel:EZD<Ph_pt>:COUPon:MEASure:FILename <String>
For a fixture modeling with the EZD tool, this command loads the coupon properties
from a Touchstone file.
Suffix:
<Ph_pt>
.
This suffix is ignored.
Parameters:
<String> Path to the Touchstone file, either absolute or relative to the cur-
rent directory (see MMEMory:CDIRectory)
Options: R&S ZNB/ZNBT-K210
Manual operation: See "Load File / 1x Open Preset / 1x Short Preset " on page 593
CALCulate:FMODel:EZD<Ph_pt>:COUPon[:STATe] <Boolean>
For a fixture modeling with the EZD tool, this command allows to specify the ports to
which the test coupon is connected.
This has to be defined before measuring the test coupon (using CALCulate:FMODel:
EZD<Ph_pt>:COUPon:MEASure).
