a) Acquire error correction data for the required ports and port pairs, and the
required standards.
b) Acquire source power calibration data at the "Power Port".
c) Finally, decide whether to apply the resulting calibration.
Background and related information
●
Refer to Chapter 5.5.7, "SMARTerCal", on page 179 for background information.
●
See Chapter 6.11.1.11, "SMARTerCal Wizard (Manual, MultiCal) ", on page 471 for
the "MultiCal" variant of the wizard.
●
Use the Power Cal Wizard to perform an additional source flatness calibration (see
Chapter 5.5.7.3, "Combining SMARTerCal with Scalar Power Calibration",
on page 180).
●
If the active channel is already calibrated, the wizard attempts to load the calibra-
tion. If the calibration setup is unchanged and sweep data are available, the exist-
ing system error correction can be optimized without repeating the measurement of
all standards.
●
When you apply the acquired SMARTerCal, the active calibration is replaced and
discarded.
To persist any kind of calibration, you can transfer it to the cal "Pool" using the Cali-
bration Manager Dialog.
●
The active system error correction data can be read (and modified) using the
remote control command [SENSe<Ch>:]CORRection:CDATa.
If external switch matrices are involved, use [SENSe<Ch>:]CORRection:
SMATrix:CDATa instead.
Step 1: Ports and Type
Selects the calibrated analyzer ports, the calibration type and specifies the power
meter connection.
Background information
Refer to Chapter 5.5.7.2, "Calibration Types", on page 180.
Cal Softtool
