Remote control via GPIB
To control external devices via GPIB, you have to use an Chapter 5.7.24, "USB-to-IEC/
IEEE Adapter", on page 241.
Log Errors
Enables the transfer of error messages for external devices (e.g. connection errors) to
the error log. The error log appears in the "Info" dialog; see Chapter 6.17.1.3, "Info Dia-
log", on page 710.
Remote command:
n/a
6.17.4.2 External Power Meters Dialog
The "External Power Meters" dialog configures external power meters so that they can
be used for measurements and power calibrations.
Access: SYSTEM – [SETUP] > "External Devices" > "Power Meters..."
Background information
Refer to section Chapter 5.7.25, "External Power Meters", on page 241.
The configuration of a new external power meter involves the following steps:
1. Connect the power meter to your R&S ZNB/ZNBT using a LAN (VXI-11), GPIB, or
USB interface.
2. If the power meter is connected via LAN, enable LAN Detection
3. Select Scan Instruments and wait until the power meter appears in the table of
"Known Devices".
