Parameters:
<Command> 3 to 37 hexadecimal digits (0-F), defining the command to be
executed: digit 1 is the slave address, digits 2 and 3 specify the
command number and the remaining digits represent the data
part (up to 17 digit pairs).
Manual operation: See "RFFE columns (sweep sequencer table)" on page 522
8.3.4 DIAGnostic Commands
The DIAGnostic... commands provide access to service and diagnostic routines
used in service, maintenance and repair. In accordance with the SCPI standard, all
commands are device-specific.
Service functions are password-protected (SYSTem:PASSword[:CENable]) and are
intended for Rohde & Schwarz service staff. Refer to the service manual for more infor-
mation.
DIAGnostic:DEVice:STATe............................................................................................ 1021
DIAGnostic:DUMP:SIZE............................................................................................... 1021
DIAGnostic:PRODuct:OPTion:INFO?............................................................................. 1022
DIAGnostic:SERVice:RFPower......................................................................................1022
DIAGnostic:SERVice:SFUNction....................................................................................1022
DIAGnostic:DEVice:STATe <Filename>
Generates a system report and writes it to the specified file. See Chapter 10.3, "Col-
lecting Information for Technical Support", on page 1421.
Setting parameters:
<Filename> String parameter containing the file name. If no path is specified,
the file is stored to the directory
C:\Users\Public\Documents\Vna\Report; the extension
*.zip is appended automatically.
*RST: n/a
Example:
DIAG:DEV:STAT 'report_16032011_1120'
Generate a report and store it to
C:\Users\Public\Documents\Vna\Report\
report_16032011_1120. Use the MMEMory... commands to
rename, move, or delete the file.
Usage: Setting only
Manual operation: See "Save..." on page 710
DIAGnostic:DUMP:SIZE <DumpSize>
Determines the level of detail and hence the size of the dump files created in case of
firmware exceptions.
