Remote command:
CALCulate<Ch>:TRANsform:VNETworks:DIFFerential:
EMBedding<LogPt>[:STATe]
File Name 1
The ellipsis button in the "File Name 1" column is enabled if a 2-port data Network is
selected.
When loading the touchstone file (*.s2p), the analyzer by default assumes odd ports
left (VNA side), even ports right (DUT side). However, it is also possible to "Swap
Gates", instructing the analyzer to reinterpret the loaded S-parameters (e.g. S
12
-->
S
21
).
Note: The loaded S-parameter traces are stored in the active recall set. Persisted
recall sets contain the full embedding and deembedding data so that they can be trans-
ferred to other instruments.
Remote command:
MMEMory:LOAD:VNETworks<Ch>:DIFFerential:EMBedding<LogPt>
6.13.2 Offset Tab
Defines length offset parameters for each port.
Use the complementary dock widget to activate or deactivate length/loss compensation
for selected ports (see Chapter 6.13.1.2, "Offset Panel", on page 569).
The marker function Zero Delay at Marker function overwrites the offset parameters.
Background information
Refer to the following sections.
●
Chapter 5.6, "Offset Parameters and De-/Embedding", on page 182
●
Chapter 5.6.1.1, "Definition of Offset Parameters ", on page 182
●
Chapter 5.6.1.3, "Auto Length", on page 183
●
Chapter 5.6.1.6, "Application and Effect of Offset Parameters ", on page 187
●
Chapter 5.6.1.7, "Offset Parameters for Balanced Ports", on page 188
●
Chapter 5.6.1.5, "Fixture Compensation ", on page 186
Offset Embed Softtool
