GUI Reference
R&S
®
ZNB/ZNBT
630User Manual 1173.9163.02 ─ 55
Windows Explorer
Opens the Windows Explorer and shows you the contents of the
C:\Users\Public\Documents\Rohde-Schwarz\Vna\External Tools appli-
cation shortcut directory.
6.15.2 TDR Application (R&S ZNB/ZNBT-K20)
The "TDR" (Time Domain Reflectometry) application is provided by the Extended Time
Domain Analysis option R&S ZNB/ZNBT-K20. It is only visible if this option is installed.
Access: SYSTEM – [APPLIC] > "TDR"
Background information
See Chapter 5.7.2.7, "Extended Time Domain Analysis", on page 209.
6.15.2.1 TDR Setup Tab
The "TDR Setup" tab allows you to set up the measurement for the time domain trans-
formation, which is then used to analyze the time domain behavior of the DUT (eye
diagram, rise time, skew, ...).
Access: SYSTEM – [APPLIC] > "TDR" > "TDR Setup"
Applic Softtool
