Top = Default offset calculation
Bottom = Offset calculation after de-/embedding (GUI mockup)
Remote command:
[SENSe:]CORRection:EDELay:VNETwork
6.13.11 Delta-L Tab
The controls on the "Delta-L" tab allow you to set up and perform a Delta-L PCB char-
acterization.
The "Delta-L" tab is only visible if option R&S ZNB/ZNBT-K231 is installed on the
instrument. See Chapter 5.7.11, "Delta-L 4.0 PCB Characterization", on page 230.
The "Delta-L Settings..." button opens the Delta-L Settings Dialog, which allows you to
configure a Delta-L measurement . The "Delta-L Measurement" button runs the config-
ured measurement.
