Command Reference
R&S
®
ZNB/ZNBT
1086User Manual 1173.9163.02 ─ 55
Manual operation: See "File Name 1" on page 576
MMEMory:LOAD:VNETworks<Ch>:GLOop:EMBedding<group> <TouchstoneFile>
Loads data from a specified one-port (*.s1p) Touchstone file defining a ground loop
circuit model for embedding.
The query returns the name of the loaded file.
Suffix:
<Ch>
.
Channel number
<group> Port group (DUT) number.
If multiple port groups are configured (see SOURce<Ch>:
GROup<Grp>:PPORts) and CALCulate<Ch>:TRANsform:
VNETworks:GLOop:GROup is ON, then each port group can
have its own de-/embedding models.
Parameters:
<TouchstoneFile> String parameter to specify the name and directory of the loaded
Touchstone file.
If no path is specified the analyzer searches the current direc-
tory, which can be set and queried using MMEMory:
CDIRectory
Example:
CALC:TRAN:VNET:SEND:GLO:TND FIMP
Select the 1-Port Data (s1p) circuit model.
MMEM:LOAD:VNET:GLO:EMB 'C:\Users\Public\
Documents\Rohde-Schwarz\Vna\Embedding\Test.s1p'
Load a Touchstone file.
Manual operation: See "File Name 1" on page 576
MMEMory:LOAD:VNETworks<Ch>:PPAir:DEEMbedding<ListId>
<TouchstoneFile>[, <Interchange>]
Loads data from the specified Touchstone file into the deembedding model of port set
<ListId>. Only takes effect, if the deembedding model of port set <ListId> actually
involves Touchstone files.
The query returns the name of the loaded file.
Suffix:
<Ch>
.
Channel number
<ListId> Index of the port set within the channel's overall list of port sets
for deembedding.
SCPI Command Reference
