2. Activate the desired softtool tab, e.g. "Z←Sij".
3. Select a control element, e.g. "Z←S11".
The diagram immediately reflects your selection. The active trace shows the mea-
surement results for the selected measured quantity.
A control element with three dots (e.g. SYSTEM – [SETUP] > "Setup" > "System Con-
fig...") opens a dialog, containing a group of related settings, a wizard or additional
information.
