Command Reference
R&S
®
ZNB/ZNBT
894User Manual 1173.9163.02 ─ 55
Type Complete List Description
Special Functions StimVal Current stimulus value (see description of operators
for User Defined Math)
Brackets ( ) Priority of operations in complex expressions
CALCulate<Chn>:MATH:FUNCtion <Mode>
CALCulate<Chn>:MATH:FORMatted:FUNCtion <Mode>
Defines a simple mathematical trace based on the active trace and its active memory
trace. The first command applies to raw, unformatted trace data (complex data), the
second to formatted trace data. Both methods can be combined.
To apply the trace math, the corresponding mathematical mode must be switched on
using CALCulate<Chn>:MATH:STATe ON and/or CALCulate<Chn>:MATH:
FORMatted:STATe ON.
Note: Use CALCulate<Chn>:MATH[:EXPRession]:SDEFine and/or
CALCulate<Chn>:MATH:FORMatted[:EXPRession]:SDEFine to define general
math traces.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<Mode> NORMal | ADD | SUBTract | MULTiply | DIVide
NORMal – Math. trace = active data trace
ADD – Math. trace = data + memory
SUBTract – Math. trace = data - memory
MULTiply – Math. trace = data * memory
DIVide – Math. trace = data / memory
When set to NORMal, the corresponding mathematical mode is
turned OFF, otherwise it is turned ON.
*RST: NORMal
Example:
*RST; :CALC:MATH:MEM
Copy the current state of the default trace 'Trc1' to a memory
trace named 'Mem2[Trc1]'. The memory trace is not dis-
played.
CALC:MATH:FUNC DIV
Define a mathematical trace, dividing the raw complex data
trace trace by the stored memory trace. The mathematical trace
is displayed instead of the active data trace.
CALC:MATH:STAT?
The response is 1 (mathematical mode for unformatted trace
data switched on, mathematical trace displayed).
Manual operation:
See "Data / <Mem>, Data - <Mem>" on page 312
