Raymarine LIGHTHOUSE 4 User Manual

Feature/setting
R
adartype
A
utoacquisitionofRadar
targets
•Cyclone—Solidstateopenarray
•Magnum—Openarray
•Quantum™2Doppler—Radome
T
uning
•Magnum—Openarray
•SuperHD™—Openarray
•HD—Openarray
•HD—Radome
TransmitFrequency
•Cyclone—Solidstateopenarray
•Quantum™2Doppler—Radome
•Quantum™—Radome
ScannerR otationSpeed•Cyclone—Solidstateopenarray=12
RPM,24RPM,36RPM,48RPM,60RPM
andAuto
•Magnum—Openarray=24RPMand
Auto(48RPM)
•Quantum™2Doppler—Radome=24RPM
•Quantum™—Radome=24RPM
•SuperHD™—Openarray=24RPMand
Auto(48RPM)
•HD—Openarray=24RPMandAuto(48
RPM)
•HD—Radome=24RPMandAuto(48
RPM)
•Digital—Radome(non-HD)=24RPM
SeaClutterCurve
•All
P arkingOffset•Magnum—Openarray
•SuperHD™—Openarray
•HD—Openarray
Feature/setting
R
adartype
AntennaSizeselection•Magnum—Openarray
•SuperHD™—Openarray=4ft/6ft
•HD—Openarray=4ft/6ft
Note:
Antennasizeselection(i.
e.:3ft,4ftor
6ft)forCycloneradarsisautomatically
detectedandcannotbeselected
manually.
TimedTransmit•All
BearingAlignment•All
MBS(MainBang
Suppression)Off
•All
TuningPreset
•Magnum—Openarray
•SuperHD™—Openarray
•HD—Openarray
•HD—Radome
•Digital—Radome(non-HD)
STC(SensitivityTime
Control)Preset
•Digital—Radome(non-HD)
VRM/EBL(VariableRange
Markers/ElectronicBearing
Line)
•All
DisplayTiming
•SuperHD™—Openarray=0–767m
•HD—Openarray=0–767m
•HD—Radome=0–767m
•Digital—Radome(non-HD)=0–153.6m
R adarapp
281

Raymarine LIGHTHOUSE 4 Specifications

General

Operating System	LightHouse 4
Touchscreen	Yes
Connectivity	NMEA2000, Ethernet, Wi-Fi
Chart Compatibility	Navionics, C-MAP
Display Size	Varies by model (e.g., 7", 9", 12", 16")
Display Resolution	Varies by model
Networking	Ethernet, Wi-Fi
GPS	Built-in
Radar Support	Yes, compatible with Raymarine radars
Sonar Support	Yes
Autopilot Integration	Yes, compatible with Raymarine autopilot systems
Weather Data	Yes, via internet
Software Updates	Via Wi-Fi
