Configuration SpaceBCM5718 Programmer’s Guide
Broadcom®
January 29, 2016 • 5718-PG108-R Page 180
The Ethernet controller resources listed in the following are decoded in the 64K address block.
32K is partitioned for MAC control registers and 32K available for a memory access window. Range 0x0000–
0x00FF is a complete shadow of the PCI configuration space registers—host software can also read/write to the
Ethernet controller’s PCI configuration space registers via the host memory map. Host software may use the
shadow registers to change PCI register contents and avoid PCI configuration cycles (transactions). Again,
using the host memory map is slightly more efficient. The MAC’s control/status registers are mapped from
0x0400–0x8000. See Section 13: “Ethernet Controller Register Definitions,” on page 269 for complete register
and bit definitions. Finally, the memory window range is 0x8000–0xFFFF. This 32K window is set in the PCI
Configuration space using the Memory_Window_Base_Address register (see Figure 38). Bits 23:15 set the
window aperture and bits 14:2 are effectively ignored/masked off. Bits 14–2 are relevant when host software
uses memory indirection and the Memory_Window_Data register.
Figure 38: Memory Window Base Address Register
Figure 39 on page 181 shows how the 32K window can float in the Ethernet controller’s local memory. The
window aligns on 32K boundaries.
Example: The memory window may start on the following addresses: 0x8000, 0x10000, and 0x18000. The
window aperture may be positioned in the internal memory range 0x00000000 to 0x0001FFFF. When host
software reads/writes to PCI_BAR + 32K + OFFSET in the host memory space, the Ethernet controller
translates this read/write access to Memory_Window_Base_Address + OFFSET. Host software must not
read/write from any address greater than PCI_BAR + 64K, since this memory space is not decoded by the
Ethernet controller. Such an access may be decoded by another device, or simply go unclaimed on the PCI
bus. Figure 39 on page 181 shows the relationship between the Memory_Window_Base_Address register
and the Memory Window.
Table 48: PCI Address Map Standard View
Offset Name Size
0x00000000–0x000000ff PCI Configuration space 256 bytes
0x00000200–0x000003ff High-Priority Mailboxes 512 bytes
0x00000400–0x00007fff Ethernet controller registers 31 KB
0x00008000–0x0000ffff Memory Window 32 KB
Rsvd Window Rsvd
[31:24] [14:2] [1:0]
XXXX (Dont Care)
[23:15]
Window aprerature
set by bits 23-15
These bits are
ignored - 32K window
position.
