Send BD Completion Control RegistersBCM5718 Programmer’s Guide
Broadcom®
January 29, 2016 • 5718-PG108-R Page 356
Send BD Completion Control Registers
All registers reset are core reset unless specified.
Send BD Completion Mode Register (offset: 0x1C00)
Name Bits Access
Default
Value
Description
Reserved 31:3 RO 0 –
Attention Enable 2 RW 0 When this bit is set to 1, an internal attention is
generated when an error occurs.
Enable 1 RW 1 This bit controls whether the Send BD
Completion state machine is active or not. When
set to 0, it completes the current operation and
cleanly halts.
Until it is completely halted, it
remains 1 when read
–
Reset 0 RW 0 When this is set to 1, the Send BD Completion
State machine is reset.
This is a self clearing bit –
