Broadcom NetXtreme/NetLink BCM5718 Series User Manual

Central Power Management Unit (CPMU) RegistersBCM5718 Programmer’s Guide
Broadcom®
January 29, 2016 • 5718-PG108-R Page 411
Current Measurement Upper 32-bit Read Register (offset: 0x36D8)
Current Measurement Lower 32-bit Read Register (offset: 0x36DC)
Global Mutex Request Register (offset: 0x36F0)
This register is reset by POR Reset or CPMU Register Software Reset.
Name Bits Access
Default
Value
Description
Upper 32-bit of Current
Measurement Count
31:0 RO 0x0 Please refer to 0x36D4[1:0]
Name Bits Access
Default
Value
Description
Lower 32-bit of Current
Measurement Count
31:0 RO 0x0 Please refer to 0x36D4[1:0]
Note: This register is for BCM5719/BCM5720 only.
Name Bits Access
Default
Value
Description
Reserved 31:8 DC 0 –
Set Request/Request Pending 7:0 RW 1S 0x0 Writing a 1 to any of these bits pends a Mutex
lock request on behalf of a s/w agent. The bit is
subsequently latched by hardware and shall read
1 as long as the request is pending. Writing a 0
to a bit shall have no effect. Reading this field
may return zero or more bits with value 1–each
bit with value 1 indicates a pending request.
