Broadcom NetXtreme/NetLink BCM5718 Series User Manual

PCI Configuration RegistersBCM5718 Programmer’s Guide
Broadcom®
January 29, 2016 • 5718-PG108-R Page 304
Correctable Error Status Register (offset: 0x110)
Correctable Error Mask Register (offset: 0x114)
Name Bits Access
Default
Value
Description
Reserved 31:14 RO 0 –
Advisory Nonfatal Error Status 13 RO 0 This bit is set when an Advisory Nonfatal error
occurs.
Replay Timer Timeout Status 12 RW1CS 0 This bit is set when a Replay Timer Timeout error
occurs.
Reserved 11:9 RO 0 –
REPLAY_NUM Rollover
Status
8 RW1CS 0 This bit is set when a REPLAY_NUM Rollover
error occurs.
Bad DLLP Status 7 RW1CS 0 This bit is set when a Bad DLLP error occurs.
Bad TLP Status 6 RW1CS 0 This bit is set when a Bad TLP error occurs.
Reserved 5:1 RO 0 –
Receiver Error Status 0 RW1CS 0 This bit is set when a Receiver error occurs.
Name Bits Access
Default
Value
Description
Reserved 31:14 RO 0 –
Advisory Nonfatal Error Mask 13 RWS 1 Setting this bit masks Advisory Nonfatal errors.
Replay Timer Timeout Mask 12 RWS 0 Setting this bit masks Replay Timer Timeout
errors.
Reserved 11:9 RO 0 –
REPLAY_NUM Rollover Mask 8 RWS 0 Setting this bit masks REPLAY_NUM Rollover
errors.
Bad DLLP Mask 7 RWS 0 Setting this bit masks Bad DLLP errors.
Bad TLP Mask 6 RWS 0 Setting this bit masks Bad TLP errors.
Reserved 5:1 RO 0 –
Receiver Error Mask 0 RWS 0 Setting this bit masks Receiver errors.
