Statistics RegistersBCM5718 Programmer’s Guide
Broadcom®
January 29, 2016 • 5718-PG108-R Page 341
HTX2B Statistics
The HTX2B statistics reside in Transmit MAC. A counter is automatically reset to 0 by hardware upon a Read
Operation. All counters roll over.
B2HRX Statistics
The B2HRX statistics reside in RDI.
Receive MAC Static Counters
ifHCInOctets (offset: 0x880)
The number of octets received on the interface, including frame characters.
ifHCINOctets_bad (offset: 0x884)
The number of bad octets received on the interface.
etherStatsFragments (offset: 0x888)
A frame size that is less than 64 bytes with a bad FCS.
Statistics Name
Set1
Address
Set2
Address
Size Description
HTX2B Octets 0x700 0x720 32 Total number of H2B octets.
HTX2B UCAST PKTS 0x704 0x724 32 Number of H2B unicast frames.
HTX2B MCAST PKTS 0x708 0x728 32 Number of H2B multicast.
HTX2B BCAST PKTS 0x70C 0x72C 32 Number of H2B broadcast frames.
HTX2B DROP PKTS 0x710 0x730 32 Number of H2B frames dropped by
EMAC.
HTX2B DROP OCTETS 0x714 0x734 32 Total number of H2B octets dropped by
EMAC.
Statistics Name
Set1
Address
Set2
Address
Size Description
B2HRX OCTETS 0x24D0 0x24E8 32 Total number of H2B octets.
B2HRX UCAST PKTS 0x24D4 0x24EC 32 Number of B2H unicast frames.
B2HRX MCAST PKTS 0x24D8 0x24F0 32 Number of B2H multicast frames.
B2HRX BCAST PKT 0x24DC 0x24F4 32 Number of B2H broadcast frames.
B2HRX DROP PKTS 0x24E0 0x24F8 32 Number of B2H frames dropped by
RDI.
B2HRX DROP OCTETS 0x24E4 0x24FC 32 Total number of B2H octets
dropped by RDI.
