PCI Configuration RegistersBCM5718 Programmer’s Guide
Broadcom®
January 29, 2016 • 5718-PG108-R Page 300
SLOT_CAPABILITY_2 – 0xe0
SLOT_STATUS_CONTROL_2 – 0xe4
Product ASIC ID (offset: 0xF4)
TARGET_LINK_SPEED 3:0 RW 0x1 Upper limit of link speed
Path= i_cfg_func.i_cfg_public.i_cfg_exp_cap
Name Bits Access
Default
Value
Description
SLOT_CAPABILITY_2 31:0 RO 0 Not implemented
Name Bits Access
Default
Value
Description
SLOT_STATUS_2 31:16 RO 0 Not implemented
SLOT_CONTROL_2 15:0 RO 0 Not implemented
Name Bits Access
Default
Value
Description
Product ASIC ID 31:0 RO For 5717 B0, value is 0x05717100:
• 5718 A0, value is 0x05717000
• 5718 B0, value is 0x05717100
• 5719 A0, value is 0x05719000
• 5719 A1, value is 0x05719100
• 5720 AO, value is 0x05720000
Name Bits Access
Default
Value
Description
Value Name Description
0 2_5 2.5 Gbps
1 5_0 5.0 Gbps
255 – end_of_table
