Host Coalescing Control RegistersBCM5718 Programmer’s Guide
Broadcom®
January 29, 2016 • 5718-PG108-R Page 422
Status Block 16 Host Address Register (offset: 0x3D78)
Status Block Base Address Register (offset: 0x3C44)
This 32-bit register is the location of the status block structure in NIC memory.
Flow Attention Register (offset: 0x3C48)
The Flow attention register reports attentions from the various transmit and receive state machines, flow-
through queues and the MBUF allocator. Whenever one of these blocks detects an attention situation, it sets
the appropriate bit in the Flow attention register. Refer to the state machine causing the attention to determine
the exact cause. The attention bits are cleared by writing a one to the bit (W2C). If a bit is marked as fatal, it
means that the associated state machine is halted, and that corrective action must be taken by a CPU.
Note: This register should always be set to 0xB00. See Appendix C: “Device Register and Memory
Map,” on page 580 for details.
Name Bits Access
Default
Value
Description
Send BD Initiator 31 W2C – The Send BD Initiator state machine has caused
an attention.
Send BD Completion 30 W2C – The Send BD Completion state machine has
caused an attention.
Send BD Ring Selector 29 W2C – The Send BD Ring Selector state machine has
caused an attention.
Send Data Initiator 28 W2C – The Send Data Initiator state machine has
caused an attention.
Send Data Completion 27 W2C – The Send Data Completion state machine has
caused an attention.
Reserved 26:24 RO 0 –
Recv BD Initiator 23 W2C – The Recv BD Initiator state machine has caused
an attention.
Recv BD Completion 22 W2C – The Recv BD Completion state machine has
caused an attention.
Recv List Placement 21 W2C – The Recv List Placement state machine has
caused an attention.
Recv List Selector 20 W2C – The Recv List Selector state machine has
caused an attention.
Recv Data and Recv BD
Initiator
19 W2C – The Recv Data and Recv BD Initiator state
machine has caused an attention.
Recv Data Completion 18 W2C – The Recv Data Completion state machine has
caused an attention.
RCB Incorrectly Configured 17 W2C – Set if one of the RCBs is incorrectly configured
based on the whole configuration.
DMA Completion Discard 16 W2C – The DMA Completion Discard state machine has
caused an attention.
