Receive List Placement RegistersBCM5718 Programmer’s Guide
Broadcom®
January 29, 2016 • 5718-PG108-R Page 359
Receive List Placement Statistics Control Register (offset: 0x2014)
Receive List Placement Statistics Enable Mask Register (offset:
0x2018)
Name Bits Access
Default
Value
Description
Reserved 31:3 RO 0 –
Statistics Clear 2 RW 0 When set, resets local statistics counters to zero.
Clears only masked statistics.
Self-clearing when done.
Reserved 1 RO 0 –
Statistics Enable 0 RW 0 When set, allow the local statistics counters to
increment.
When reset, counters hold their values until the
next update to the NIC memory.
Enables only masked statistics.
Name Bits Access
Default
Value
Description
Reserved 31:26 RO 0 –
RSS_Priority 25 RW 0x0 This bit enables the receive packet to choose
receive return ring in terms of RSS hash value
instead of RC class when both RSS and RC rules
are matched. Default is to give priority to RC.
RC Return Ring Enable 24 RW 0x0 1: Enable receive packet to use RC rule class as
return ring number if RC rule is matched. This bit
will be used in conjunction with bit25 to derive the
final receive return ring.
0: Disable receive packet to use RC rule class as
return ring number. Receive packet only uses
RSS hash to select the receive return ring. If no
any RSS hash types are applied, the default ring
0 will be used.
CPU MACTQ Priority Disable 23 RW 0x0 1: Disable CPU priority over SDC when
arbitrating the MACTQ write requests.
0: Enable CPU priority over SDC when
arbitrating the MACTQ write requests.
Reserved 22:19 RO 0 –
Disable MACTQ Double Ack
issue fix
18 RW 1 Disable MACTQ double ack issue fix.
1: Disabled
0: Enabled
Reserved 17:2 RO N/A –
Disable ASF Lockup Issue Fix 1 RW 1 Disable ASF Lockup Fix.
1: Disabled
0: Enabled
