Register Field Access TypeBCM5718 Programmer’s Guide
Broadcom®
January 29, 2016 • 5718-PG108-R Page 496
Register Field Access Type
Transceiver Register Map
RW = read/write H = forced high
RO = read only L = forced low
LH = latches high value (until read) SC = self-clearing
LL = latches low value (until read) CR = clear on read
Address Name
00h MII_Control_Register
01h MII_Status_Register
02h PHY_Identifier_MSB_Register
03h PHY_Identifier_LSB_Register
04h Auto_Negot_Advertisement_Register
05h Auto_Negot_Link_Partner_Ability_Base_Pg_Register
06h Auto_Negot_Expansion_Register
07h Auto_Negot_Next_Page_Transmit_Register
08h Auto_Negot_Link_Partner_Ability_Nxt_Pg_Register
09h 1000Base_T_Control_Register
0Ah 1000Base_T_Status_Register
0Bh–0Eh Reserved_by_IEEE
0Fh IEEE_Extended_Status_Register
10h PHY_Extended_Control_Register
11h PHY_Extended_Status_Register
12h Receive_Error_Counter_Register
13h False_Carrier_Sense_Counter_Register
14h Local_Remote_Rcvr_NOT_OK_Counters_Register
15h DSP_Coefficient_Read_Write_Port_Register
16h DSP_Control_Register
17h DSP_Coefficient_Address_Register
