Broadcom NetXtreme/NetLink BCM5718 Series User Manual

Central Power Management Unit (CPMU) RegistersBCM5718 Programmer’s Guide
Broadcom®
January 29, 2016 • 5718-PG108-R Page 401
Link Idle Control Register (offset: 0x3670)
This register is reset by POR Reset or CPMU Register Software Reset.
Name Bits Access
Default
Value
Description
Reserved 31:25 DC 0 Readable and writeable reserved bits.
PCIE Idle 24 RW 1 Link idle/Host Access condition control.
1: disable this idle condition when entering link
idle mode and host access mode.
0: enable this idle condition when entering link
idle mode and host access mode
APE ATP Empty 23 RW 0 Link idle/Host Access condition control.
1: disable this idle condition when entering link
idle mode and host access mode.
0: enable this idle condition when entering link
idle mode and host access mode.
APE ATPM Idle 22 RW 0 Link idle/Host Access condition control.
1: disable this idle condition when entering link
idle mode and host access mode.
0: enable this idle condition when entering link
idle mode and host access mode.
DBU Idle 21 RW 0 Link idle/Host Access condition control.
1: disable this idle condition when entering link
idle mode and host access mode.
0: enable this idle condition when entering link
idle mode and host access mode.
NVM Idle 20 RW 0 Link idle/Host Access condition control.
1: disable this idle condition when entering link
idle mode and host access mode.
0: enable this idle condition when entering link
idle mode and host access mode.
SBDI Idle 19 RW 0 Link idle/Host Access condition control.
1: disable this idle condition when entering link
idle mode and host access mode.
0: enable this idle condition when entering link
idle mode and host access mode.
RBDI Idle 18 RW 0 Link idle/Host Access condition control.
1: disable this idle condition when entering link
idle mode and host access mode.
0: enable this idle condition when entering link
idle mode and host access mode
MB Idle 17 RW 0 Link idle/Host Access condition control.
1: disable this idle condition when entering link
idle mode and host access mode.
0: enable this idle condition when entering link
idle mode and host access mode.
Reserved 16 DC 0 –
