Central Power Management Unit (CPMU) RegistersBCM5718 Programmer’s Guide
Broadcom®
January 29, 2016 • 5718-PG108-R Page 400
EAV Clock Policy 19:12 RW 0x0 Software Controlled EAV Clock Speed Select
00000000: divide-by-256 -- Clock frequency
4.8 MHz
00000001: divide-by-1 -- Clock frequency 1250
MHz (Unused for EAV)
00000010: divide-by-2 -- Clock frequency
625 MHz (Unused for EAV)
...
00001010: divide-by-10 -- Clock frequency of
125 MHz
00001011: divide-by-11 -- Clock frequency of
113.6 MHz
....
11111111=divide-by-255 -- Clock frequency of 4.9
MHz
Reserved 11 DC 0 –
Flash Idle Clock Policy 10:8 RW 0x2 Software Controlled Flash Clock Speed
Select000: 62.5 MHz (NCSI DLL) 010: 25 MHz
(CK25)
Reserved 7 DC 0 –
Flash Clock Policy 6:4 RW 0x0 Software Controlled Flash Clock Speed
Select000: 62.5 MHz (NCSI DLL) 010: 25 MHz
(CK25)
Reserved 3 DC 0 –
Override Flash Clock Switch 2:0 RW 0x2 Software Controlled Flash Clock Speed
Select000: 62.5 MHz (NCSI DLL) 010: 25 MHz
(CK25)
Name Bits Access
Default
Value
Description
