Broadcom NetXtreme/NetLink BCM5718 Series User Manual

Send Data Initiator RegistersBCM5718 Programmer’s Guide
Broadcom®
January 29, 2016 • 5718-PG108-R Page 346
Send Data Initiator Statistics Mask Register (offset: 0xC0C)
Send Data Initiator Statistics Increment Mask Register (offset: 0xC10)
Local Statistics Register (offset: 0xC80–0xCDF)
Zap Statistic 4 RW 0 –
Flush Statistic 3 RW 0 –
Statistics Clear 2 RW 0 If set, resets local statistics counters to zero.
Clears only masked statistics.
Self-clearing when done.
Faster Update 1 RW 0 –
Statistics Enable 0 RW 0 When set, allows the local statistics counters to
increment. When reset, counters hold their
values until next update to NIC memory.
Enables only masked statistics.
Name Bits Access
Default
Value
Description
Reserved 31:1 RO 0 –
Counters Enable Mask 0 RW 0 Controls whether Class of Service 0 statistics
can be updated, cleared, or flushed.
Name Bits Access
Default
Value
Description
Reserved 31:24 RO 0 –
Counters Increment Mask 23:19 WO 0 Writing 1 to the bit position forces the
corresponding statistics counters to increment by
1. Not affected by Statistics Enable Mask.
Bits 16:23 correspond to Set Send Producer
Index, Status Updated, Interrupts, Avoided
Interrupts, Send Threshold Hit respectively.
Reserved 18:16 RO 0 –
Counters Increment Mask 15:0 WO 0 Writing 1 to the bit position forces the
corresponding statistics counters to increment by
1. Not affected by Statistics Enable Mask.
Bits 15:0 correspond to statistics for Class of
Service 16:1
Name Bits Access
Default
Value
Description
Reserved 31:10 RO 0 –
Name Bits Access
Default
Value
Description
