Broadcom NetXtreme/NetLink BCM5718 Series - 1 Eh: Test1_Register

10h–1Fh Register Map Detailed DescriptionBCM5718 Programmer’s Guide
Broadcom®
January 29, 2016 • 5718-PG108-R Page 545
1Eh: Test1_Register
8 * HCD 100T RO
LH
1 = 100tx half-duplex hcd occurred since last
read
0 = hcd cleared
0
7 * HCD 10T FDX RO
LH
1 = 10base-t full-duplex hcd occurred since last
read
0 = hcd cleared
0
6 * HCD 10T RO
LH
1 = 10base-t half-duplex hcd occurred since last
read
0 = hcd cleared
0
5 * HCD 1000T FDX
(Link never came up)
RO
LH
1 = Gigabit full-duplex hcd and link never came
up occurred since last read
0 = hcd cleared
0
4 * HCD 1000T
(Link never came up)
RO
LH
1 = Gigabit half-duplex hcd and link never came
up occurred since last read
0 = hcd cleared
0
3 * HCD 100T FDX
(Link never came up)
RO
LH
1 = 100tx full-duplex hcd and link never came up
occurred since last read
0 = hcd cleared
0
2 * HCD 100T
(Link never came up)
RO
LH
1 = 100tx half-duplex hcd and link never came
up occurred since last read
0 = hcd cleared
0
1 * HCD 10T FDX
(Link never came up)
RO
LH
1 = 10base-t full-duplex hcd and link never
came up occurred since last read
0 = hcd cleared
0
0 * HCD 10T
(Link never came up)
RO
LH
1 = 10base-t half-duplex hcd and link never
came up occurred since last read
0 = hcd cleared
0
* Bits [12:0] also cleared on restarting or disabling auto-negotiation.
Bit Name RW Description Default
15 CRC ERROR COUNT
VISIBILITY
RW 1 = receiver NOT_OK counters merged into one 16 bit
counter to count CRC errors instead
(crc errors will only be counted after this bit
is set!)
0 = normal operation
0
14 TRANSMIT ERROR
CODE VISIBILITY
RW 1 = false carrier sense counter counts packets received
with transmit error codes instead
(errors will only be counted after this bit is set!)
0 = normal operation
0
13 COUNTER TEST MODE RW 1 = forces counters into test mode
0 = normal operation
0
Bit Name RW Description Default
