Broadcom NetXtreme/NetLink BCM5718 Series User Manual

RSS RegistersBCM5718 Programmer’s Guide
Broadcom®
January 29, 2016 • 5718-PG108-R Page 331
HTX2B Global Filter Reg (address: 0x6D4)
This register resides in TCE.
RSS Registers
All registers reset are core reset unless specified.
Indirection Table Register 0 (offset: 0x630)
Indirection Table Register 2 (offset: 0x634)
Name Bits Access
Default
Value
Description
Unused 31:2 RU 0xUUUU Unused.
HTX2B Broadcast Filter
Enable
1 RW 0 Write 1 to replicate and route all Host Send
broadcast packets to APE. This bit overrides any
conflicting Protocol Filter setting.
HTX2B Multicast Filter Enable 0 RW 0 Write 1 to replicate and route all Host Send
multicast packets to APE. This bit overrides any
conflicting Protocol Filter setting.
Name Bits Access
Default
Value
Description
table_entry0 31:28 RW 0 The RSS_ring value for entry 0.
table_entry1 27:24 RW 0 The RSS_ring value for entry 1.
table_entry2 23:20 RW 0 The RSS_ring value for entry 2.
table_entry3 19:16 RW 0 The RSS_ring value for entry 3.
table_entry4 15:12 RW 0 The RSS_ring value for entry 4.
table_entry5 11:8 RW 0 The RSS_ring value for entry 5.
table_entry6 7:4 RW 0 The RSS_ring value for entry 6.
table_entry7 3:0 RW 0 The RSS_ring value for entry 7.
Name Bits Access
Default
Value
Description
table_entry8 31:28 RW 0 The RSS_ring value for entry 8.
table_entry9 27:24 RW 0 The RSS_ring value for entry 9.
table_entry10 23:20 RW 0 The RSS_ring value for entry 10.
table_entry11 19:16 RW 0 The RSS_ring value for entry 11.
table_entry12 15:12 RW 0 The RSS_ring value for entry 12.
table_entry13 11:8 RW 0 The RSS_ring value for entry 13.
