MSI-X PlumbingBCM5718 Programmer’s Guide
Broadcom®
January 29, 2016 • 5718-PG108-R Page 246
Each replicated Status Block has its own format; however, each of the new status block formats is extrapolated
from the legacy status block format.
Single-Vector RSS Mode Status Block Format
Table 92 on page 247 shows the Status-Block format used by Vector#0 in the Single-Vector RSS mode. Note
that first 24B of this structure is identical to the legacy Status Block.
5 0x3D20,
0x3D24
0x228 VRQ5 RR Prod
Index
SBD5 Cons Index
RBD 5 Cons
Index
N/A N/A Used in MSI-X
Multivector IOV mode
for
Vector#5 -- Vector#16
6 0x3D28,
0x3D2C
0x22C VRQ6 RR Prod
Index
SBD6 Cons Index
RBD 6 Cons
Index
N/A N/A
7 0x3D30,
0x3D34
0x230 VRQ7 RR Prod
Index
SBD7 Cons Index
RBD 7 Cons
Indexes
N/A N/A
…….
..…..
……..
……..
……..
……..
…….
……..
N/A N/A –
16 0x3D78,
0x3D7C
0x254 VRQ16 RR Prod
Index
SBD16 Cons
Index
RBD 16 Cons
Index
N/A N/A –
Note: Although High Priority INT Mail Boxes are DWORD (32-bit) registers, the original four were
placed on QWORD (64-bit) boundaries for legacy PCI 64-bit target access purposes. Broadcom’s
PCIe does not allow 64-bit target accesses. Thus, the new Mailboxes are being placed 32-bits apart;
however, we are keeping the original four addresses intact.
