Ethernet MAC (EMAC) RegistersBCM5718 Programmer’s Guide
Broadcom®
January 29, 2016 • 5718-PG108-R Page 326
Receive Rules Value/Mask Registers (offset: 0x484 + 8*N)
The BCM5718 family employs eight receive rules (N = 0 to 7).
Receive Rules Configuration Register (offset: 0x500)
Name Bits Access
Default
Value
Description
Mask/Value 31:16 RW 0 For each bit set, the corresponding bit in the
value field is ignored during the rule match
process.
If bit 26 of the corresponding rule control register
is set, the field is used as an additional 16-bit
value for rule comparison.
Value 15:0 RW 0 This field specifies a 16-bit value for rule
comparison.
Name Bits Access
Default
Value
Description
Reserved 31:6 RO 0 –
No Rules Matches Default
Class
5:3 RW 0 Specifies the default class of service for the
frame if no rules are matched.
A value of 1 is the highest priority.
A value of zero will cause the frame to be
discarded.
Reserved 2:0 RO 0 –
