Broadcom NetXtreme/NetLink BCM5718 Series User Manual

VRQ Filter Set RegistersBCM5718 Programmer’s Guide
Broadcom®
January 29, 2016 • 5718-PG108-R Page 455
VRQ Filter Set Registers
The filter block may be programmed via the following set of registers:
• VRQ_FILT_ELEM_CFG_REG [0 through 31]: (Offset 0x5400–0x547C)
• VRQ_FILT_ELEM_PTTRN_REG [0 through 31]: (Offset 0x5480–0x54FC)
• VRQ_FILT_SET_MASK_REG [1 through 31]: (Offset 0x5504–0x557C)
16
IFHCOUTOCTETS 0x0BE0 32 Queue#16 Transmit
IFHCOUTUCAST 0x0BE4 32 Queue#16 Transmit
IFHCOUTMCAST 0x0BE8 32 Queue#16 Transmit
IFHCOUTBCAST 0x0BEC 32 Queue#16 Transmit
IFHCINOCTETS_GOOD 0x0BF0 32 VRQ#16 Receive
Reserved 0x0BF4 32 VRQ#16 Receive
IFHCINUCASTPKTS 0x0BF8 32 VRQ#16 Receive
IFHCINMULTICASTPKTS 0x0BFC 32 VRQ#16 Receive
Table 111: Default & Drop VRQ Statistics (Offset 0x09F7 – 0x09D0)
VRQ# Statistics Name Address Size Description
0 (Default)
IFHCINOCTETS_GOOD 0x09D0 32 Default VRQ Stats (Receive)
IFHCINOCTETS_BAD 0x09D4 32
IFHCINUCASTPKTS 0x09D8 32
IFHCINMULTICASTPKTS 0x09DC 32
IFHCINBROADCASTPKTS 0x09E0 32
17 (Drop) IFHCINOCTETS_GOOD 0x09E4 32 Drop VRQ Stats (Receive)
Reserved 0x09E8 32
IFHCINUCASTPKTS 0x09EC 32
IFHCINMULTICASTPKTS 0x09F0 32
IFHCINBROADCASTPKTS 0x09F4 32
Note: There is no equivalent of FILT_SET_CFG_REG(s) in VRQ-Filter Block. Also, Set#0 is non-
existent.
Table 110: Generic VRQ Statistics (Offset 0x0BFF – 0x0A00) (Cont.)
VRQ# Statistics Name Address Size Description
