Send BD Selector Control RegistersBCM5718 Programmer’s Guide
Broadcom®
January 29, 2016 • 5718-PG108-R Page 352
Send BD Ring Selector Local NIC Send BD Consumer Index Register
(offset: 0x1440–0x147C)
Each register applies to:
Name Bits Access
Default
Value
Description
Reserved 31:9 RO 0 –
Index 8:0 RO These bits contain the current NIC send BD
index.
Name Description
0x1440-0x1443 Send BD Ring Selector Local NIC Send BD 1 Consumer Index RO.
0x1444-0x1447 Send BD Ring Selector Local NIC Send BD 2 Consumer Index RO.
0x1448-0x144b Send BD Ring Selector Local NIC Send BD 3 Consumer Index RO.
0x144c-0x144f Send BD Ring Selector Local NIC Send BD 4 Consumer Index RO.
0x1450-0x1453 Send BD Ring Selector Local NIC Send BD 5 Consumer Index RO.
0x1454-0x1457 Send BD Ring Selector Local NIC Send BD 6 Consumer Index RO.
0x1458-0x145b Send BD Ring Selector Local NIC Send BD 7 Consumer Index RO.
0x145c-0x145f Send BD Ring Selector Local NIC Send BD 8 Consumer Index RO.
0x1460-0x1463 Send BD Ring Selector Local NIC Send BD 9 Consumer Index RO.
0x1464-0x1467 Send BD Ring Selector Local NIC Send BD 10 Consumer Index RO.
0x1468-0x146b Send BD Ring Selector Local NIC Send BD 11 Consumer Index RO.
0x146c-0x146f Send BD Ring Selector Local NIC Send BD 12 Consumer Index RO.
0x1470-0x1473 Send BD Ring Selector Local NIC Send BD 13 Consumer Index RO.
0x1474-0x1477 Send BD Ring Selector Local NIC Send BD 14 Consumer Index RO.
0x1478-0x147b Send BD Ring Selector Local NIC Send BD 15 Consumer Index RO.
0x147c-0x147f Send BD Ring Selector Local NIC Send BD 16 Consumer Index RO.
