VRQ StatisticsBCM5718 Programmer’s Guide
Broadcom®
January 29, 2016 • 5718-PG108-R Page 454
VRQ Statistics
Apart from the Generic VRQ statistics, EMAC shall also offer statistics on the RX Default VRQ and RX Drop
VRQ.
Name Bits Access
Default
Value
Description
Hardware Breakpoint 31:2 RW 0 Word address to break on.
Reserved 1 RO 0 –
Disable Hardware Breakpoint 0 RW 1 When this bit is set, the Hardware Breakpoint is
disabled.
Table 110: Generic VRQ Statistics (Offset 0x0BFF – 0x0A00)
VRQ# Statistics Name Address Size Description
1
IFHCOUTOCTETS 0x0A00 32 Queue#1 Transmit
IFHCOUTUCAST 0x0A04 32 Queue#1 Transmit
IFHCOUTMCAST 0x0A08 32 Queue#1 Transmit
IFHCOUTBCAST 0x0A0C 32 Queue#1 Transmit
IFHCINOCTETS_GOOD 0x0A10 32 VRQ#1 Receive
Reserved 0x0A14 32 VRQ#1 Receive
IFHCINUCASTPKTS 0x0A18 32 VRQ#1 Receive
IFHCINMULTICASTPKTS 0x0A1C 32 VRQ#1 Receive
2
IFHCOUTOCTETS 0x0A20 32 Queue#2 Transmit
IFHCOUTUCAST 0x0A24 32 Queue#2 Transmit
IFHCOUTMCAST 0x0A28 32 Queue#2 Transmit
IFHCOUTBCAST 0x0A2C 32 Queue#2 Transmit
IFHCINOCTETS_GOOD 0x0A30 32 VRQ#2 Receive
Reserved 0x0A34 32 VRQ#2 Receive
IFHCINUCASTPKTS 0x0A38 32 VRQ#2 Receive
IFHCINMULTICASTPKTS 0x0A3C 32 VRQ#2 Receive
…. ………. …….. – –
…. ………. ……... – –
