Broadcom NetXtreme/NetLink BCM5718 Series User Manual

Ethernet Controller Register DefinitionsBCM5718 Programmer’s Guide
Broadcom®
January 29, 2016 • 5718-PG108-R Page 269
Section 13: Ethernet Controller Register
Definitions
BCM5718 Family Register MAP
The BCM5718 family's internal register map is shown in Table 101.
Table 101: BCM5718 Family Register Map
Block Name Block Range Subblock Range Description
PCIe CFG 0x0000–0x03FF 0x0000–0x03FF PCIe Configuration Register Shadow
EMAC 0x0400–0x07FF 0x0400–0x06FF
0x0700–0x7FF
EMAC
Unused
EMAC STAT 0x0800–0x0BFF 0x0800–0x08FF
0x0900–0x0BFF
EMAC Statistics
Unused
SDI 0x0C00–0x0FFF 0x0C00–0x0CF7
0x0CF8–0x0FFF
Send Data Initiator
Unused
SDC 0x1000–0x13FF 0x1000–0x100B
0x100C–0x13FF
Send data Completion
Unused
SBDS 0x1400–0x17FF 0x1400–0x147F
0x1480–0x17FF
SBDS Registers
Unused
SBDI 0x1800–0x1BFF 0x1800–0x1847
0x1848–0x1BFF
Send BD Initiator
Unused
SBDC 0x1C00–0x1FFF 0x1C00–0x1C03
0x1C04–0x1FFF
Send BD Completion
Unused
RQP 0x2000–0x23FF 0x2000–0x2258
0x2259–0x23FF
Receive List Placement
Unused
RDI 0x2400–0x27FF 0x2400–0x24C3
0x24C0–0x27FF
Receive Data Initiator
Unused
RDC 0x2800–0x2BFF 0x2800–0x2803
0x2804–0x2BFF
Receive Data Completion
Unused
RBDI 0x2C00–0x2FFF 0x2C00–0x2C1B
0x2C1C–0x2FFF
Receive BD Initiator
Unused
RBDC 0x3000–0x33FF 0x3000–0x300F
0x3010–0x33FF
Receive BD Completion
Unused
CMPU 0x3400–0x37FF 0x3400–0x35FF
0x3600–0x3687
Central Power Management Unit
Unused
DBU 0x3800–0x3BFF 0x3800–0x3817
0x3900–0x3907
0x3908–0x3BFF
Debug Unit (UART)
Chip Debug
Unused
