SerDes PHY Register DefinitionsBCM5718 Programmer’s Guide
Broadcom®
January 29, 2016 • 5718-PG108-R Page 560
1000XSTATUS2
Register Description: 1000X Status2 Register.
Register Offset: 0x15 at Block 0
12 CRC_ERR_DETECTE
D
RO 1 = CRC error detected since last read.
0 = No CRC error detected since last read or detection is
disabled via register 0*10h bit [7].
0
11 TX_ERR_DETECTED RO 1 = Transmit error code detected since last read
(rx_data_error state in pcs receive fsm).
0 = No transmit error code detected since last read.
0
10 RX_ERR_DETECTED RO 1 = Receive error since last read (early_end state in pcs
receive fsm)
0 = No receive error since last read
0
9 CARRIER_EXT_ERR_
DETECTED
RO 1 = Carrier extend error since last read (extend_err in pcs
receive fsm)
0 = No carrier extend error since last read
0
8 EARLY_END_EXT_DE
TECTED
RO 1 = Early end extension since last read (early_end_ext in
pcs receive fsm)
0 = No early end extension since last read
0
7 LINK_STATUS_CHG RO 1 = Link status has changed since last read
0 = Link status has not changed since last read
0
6 PAUSE_RESOLUTION
_RXSIDE
RO 1 = Enable pause receive
0 = Disable pause receive
0
5 PAUSE_RESOLUTION
_TXSIDE
RO 1 = Enable pause transmit
0 = Disable pause transmit
0
4:3 SPEED_STATUS RO 1X = Gigabit
01 = 100 mbps
00 = 10 mbps
0
2 DUPLEX_STATUS RO 1 = Full-duplex
0 = Half-duplex
Note: When the ten bit interface is selected with fiber mode
(1000-X), then half-duplex will always be reported.
0
1 LINK_STATUS RO 1 = Link is up.
0 = Link is down.
Note: When the ten bit interface is selected with fiber mode
(1000-X), then link will always be down
0
0 SGMII_MODE RO 1 = SGMII mode
0 = Fiber mode (1000-X)
0
Table 137: 1000XSTATUS1 (Cont.)
Bits Name RW Description Default
