Statistics RegistersBCM5718 Programmer’s Guide
Broadcom®
January 29, 2016 • 5718-PG108-R Page 344
APE_NETWORK_STATS_REGS (Offsets 0x900–0x9BC)
These are duplicate network statistics registers meant for APE's private use. All of these registers accumulate
their respective event-counts and the counts self clear to 0 when a GRC read accesses is performed on a
register.
Statistics Name Address Size Description
Transmit Statistics
IFHCOUTOCTETS 0x900h 32
ETHERSTATSCOL 0x908h 16
OUTXONSENT 0x90Ch 16
OUTXOFFSENT 0x910h 16
MACXMITERRORS 0x0918 16
SINGLECOL 0x091C 16
MULTICOL 0x0920 16
DEFERREDXMIT 0x0924 16
EXCESSIVECOL 0x092C 16
LATECOL 0x0930 16
IFHCOUTUCAST 0x096C 32
IFHCOUTMCAST 0x0970 32
IFHCOUTBCAST 0x0974 32
CRSERRORS 0x0978 16
IFOUTDISCARDS 0x097C 16
Receive Statistics
IFHCINOCTETS_GOOD 0x0980 32
IFHCINOCTETS_BAD 0x0984 32
ETHERSTATSFRAGMENTS 0x0988 16
IFHCINUCASTPKTS 0x098C 32
IFHCINMULTICASTPKTS 0x0990 32
IFHCINBROADCASTPKTS 0x0994 32
DOT3STATSFCSERRORS 0x0998 16
DOT3STATSALIGNMENTERRORS 0x099C 16
XONPAUSEFRAMESRECEIVED 0x09A0 16
XOFFPAUSEFRAMESRECEIVED 0x09A4 16
MACCONTROLFRAMESRECEIVED 0x09A8 16
XOFFSTATEENTERED 0x09AC 16
DOT3STATSFRAMESTOOLONG 0x09B0 16
ETHERSTATSJABBERS 0x09B4 16
ETHERSTATSUNDERSIZEPKTS 0x09B8 16
