Ethernet MAC (EMAC) RegistersBCM5718 Programmer’s Guide
Broadcom®
January 29, 2016 • 5718-PG108-R Page 315
EMAC MAC Addresses 1 High Register (offset: 0x418)
EMAC MAC Addresses 1 Low Register (offset: 0x41C)
EMAC MAC Addresses 2 High Register (offset: 0x420)
EMAC MAC Addresses 2 Low Register (offset: 0x424)
EMAC MAC Addresses 3 High Register (offset: 0x428)
EMAC MAC Addresses 3 Low Register (offset: 0x42C)
Name Bits Access
Default
Value
Description
Reserved 31:16 RO 0 –
MAC Address High 15:0 RW 0 Upper 2-bytes of this node's MAC address.
Name Bits Access
Default
Value
Description
MAC Address Low 31:0 RW 0 Lower 4-byte of this node's MAC address.
Name Bits Access
Default
Value
Description
Reserved 31:16 RO 0 –
MAC Address High 15:0 RW 0 Upper 2-bytes of this node's MAC address.
Name Bits Access
Default
Value
Description
MAC Address Low 31:0 RW 0 Lower 4-byte of this node's MAC address.
Name Bits Access
Default
Value
Description
Reserved 31:16 RO 0 –
MAC Address High 15:0 RW 0 Upper 2-bytes of this node's MAC address.
Name Bits Access
Default
Value
Description
MAC Address Low 31:0 RW 0 Lower 4-byte of this node's MAC address.
