Broadcom NetXtreme/NetLink BCM5718 Series User Manual

Revision LevelsBCM5718 Programmer’s Guide
Broadcom®
January 29, 2016 • 5718-PG108-R Page 49
Revision Levels
See Table 3 for the revision levels of the Ethernet controllers covered by this document. Host software can use
the PCI Revision ID and Chip ID information in the PCI configuration registers to determine the revision level of
the Ethernet controller on the board, and then load the appropriate workaround described in the errata sheets.
The Broadcom PCI vendor ID is 0x14E4. Ta ble 3 shows the default values of PCI device IDs. These values may
be modified by firmware in accordance with the manufacturing information supplied in NVRAM (see “NVRAM
Configuration” on page 67 for more details).
High-speed on-chip Application
Processor Engine (APE)
YesYesYesYes
Wake-on-LAN (WOL) Yes Yes Yes Yes
Energy Efficient Ethernet (EEE) No Yes Yes Yes
Ethernet Audio Video (EAV) No No No No
Secure Digital (SD) Card Reader No No No No
IEEE 1588 / IEEE 802.1AS Timestamp
Support
No No Yes Yes
On-chip temperature monitor No No Yes Yes
Integrated Trusted Platform Module
(TPM) Security Engine
No No No No
Process voltage 1.2V 1.2V 1.2V 1.2V
CMOS linewidth 65 nm 65 nm 65 nm 65 nm
Table 3: Family Revision Levels
Family Member Device ID
a
a. See Device ID and Vendor ID Register (Offset: 0x00)—Function 0”, per PCI specification.
Revisio
n Level
PCI Revision
ID
b
b. See “PCI Classcode and Revision ID Register (offset: 0x8)—Function 0” as per the PCI specification. The
hardware default value of this register is 0x00. The boot code firmware programs this register with the value
as given in the table.
Chip ID
c
Product ASIC
ID
d
Errata Sheet
e
BCM5717 0x1655 A0 0x00 0xF000xxxx 0X5717000 5717-ES1xx-R
BCM5717 0x1655 B0 0x10 0xF100xxxx 0X5717100 5717-ES1xx-R
BCM5718 0x1656 A0 0x00 0xF000xxxx 0X5717000 5718-ES1xx-R
BCM5718 0x1656 B0 0x10 0xF100xxxx 0X5717100 5718-ES1xx-R
BCM5719 0x1657 A0 0x00 0xF000xxxx 0X5719000 5719-ES1xx-R
BCM5719 0x1657 A1 0x01 0XF100XXXX 0X5719100 5719-ES1XX-R
BCM5720 0X165F A0 0x00 0xF000xxxx 0X5720000 5720-ES1xx-R
Table 2: BCM5718 Family Product Features (Cont.)
Feature
BCM5717
Dual-Port
Copper
BCM5718
Dual-Port
Copper/SerDes
BCM5719
Quad-Port
Copper/SerDes
BCM5720
Dual-Port
Copper/SerDes
